Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave

Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave

  • Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave
  • Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave
Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-54-63
Payment & Shipping Terms:
Minimum Order Quantity: 10 rolls
Price: Negotiable
Packaging Details: Woven bag
Delivery Time: 3-5 work days
Payment Terms: L/C, T/T
Supply Ability: 5000 Kilogram/Kilograms per Week
Contact Now
Detailed Product Description
Product Name: Air Filter Mesh Application: Demister
Weave Style: Plain Weave Mesh Size: 500*3500 Mesh
Usage: Liquid And Air Filter Type: Knitted Wire Mesh
Feature: Corrosion Resistance Applicable Industries: Food, Medicine, Chemical Industry, Coal Mine
Material: Stainless Steel; Copper; Brass, Phosphor Bronz Processing Service: Bending, Welding, Decoiling, Cutting, Punching
High Light:

acid resistant air filter metal mesh


alkali resistant air filter metal mesh


plain weave air filter mesh

Acid And Alkali Resistant Gas-Liquid Filter Mesh Metal Woven Mesh Air Filter Mesh


1. Product introduction


Vapor-liquid filter, referred to as vapor-liquid screen, also known as foam catcher and woven wire mesh, is a kind of wire mesh woven in a special form. It is the main component used in engineering such as noise reduction and mechanical shock absorption, and is also widely used in the automotive industry and the electronics industry.

Wire diameter specification range: 0.08~0.3mm flat wire or round wire. Single-strand weaving, multi-strand weaving, metal wire and non-metal wire (various fibers) weaving, etc., can be pressed and rolled on the wire mesh into corrugated shapes of various styles and specifications, such as "herringbone" pattern according to needs.


2.Technical data of knitted wire mesh


60 60 55 55 2*4 54,24
120 15 100 100 4,5*4/2, 5*4 64,54
140 150 120 120 4,5*5,5/2,5*5,5 65
200 205 180 180 4*3,5/2,5*3,5 105,4
250 260 240 240 4*4/3*4 123,22
410 420 380 380 5,2*3,5/3*3 198
560 565 490 490 7,5*5/2*5 195,16
560 560 470 470 5*4/2,5*5 270
•A:It is the standard width of the mesh going out of the machine ,once flattened (flattened pipe)
•B:It is the maximum width the machine can deliver.
•C:It is the minimum width the machine can deliver.
•D:Number of machine needles.
•F:Mesh opening .Also included in the nominal width.Two mesh openings machines:
The first :opening is that between two needles.
The second:is that of the hole of the needle itself ,i.e,there is one opening of each altrnatively.
•G:Weight of 1linear m of flat mesh,in grammes,0.26 mm wire ,AISI 304 ,mesh at rest not drawn.

3. Product characteristic


1. A variety of materials. Knitted wire mesh of different materials can be used in different applications to meet different requirements.
2. Solid structure. The woven mesh adopts an interlocking structure, which is firm and will not loosen when used.
3. High efficiency. Woven wire mesh can be used as a defogging pad with high filtration efficiency.
4. Corrosion and rust resistance.
5. Acid and alkali resistance.
6. Temperature resistance.
7. Wide range of applications.

4. Application


1. Mainly used for processing demisters to separate droplets in gas. It can also be extruded for the manufacture of filter equipment.
2. Water removal, fog removal and dust removal for petroleum, petrochemical, chemical, light industry, medicine, metallurgy, aviation, island ships, automobiles, machinery, noise reduction and shock absorption, pressure vessels, drying towers, absorption towers, desulfurization towers, and environmental protection projects ;
3. It is used for gas-liquid separation, gas-water separation in the process of filtration, screening, catalyst and distillation, evaporation, absorption and so on.
4. Knitted wire mesh is widely used as defogging pad for gas-liquid separator.
5. Knitted mesh can be used for cleaning machine, kitchen and other parts.


5. Company introduction


Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.


6. AFQ


1.Q:Can you provide free samples?
A:Sorry, Free samples are not available. But after you place the order, samples cost would be return. Which is "FREE" in some way.

2.Q:Can we have the company LOGO to be printed on the products?
A:Of course. Private Label is absolutely welcome.

3. Q: Can you give me a discount price?
A: It is depending on the volume. The larger the volume is, the more discount you can enjoy.


4.Q:How do you guarantee your quality ?
A: Our workers and technical employees are with many years experiences to ensure the products are good. After production finished,check will be made by quality inspector.


5. Q:How can you guarantee the quality of mass production is same with the sample sent to me before?
A: Our warehouse staff will leave another same sample in our company, with your company name marked on it, which our production will be based on.


6. Q: How can you deal with quality issues that customers feedback after receiving the goods?
A: We will follow below steps to solve the quality issues the may occur.
1) Customers take photos of unqualified goods and then our sales staff will send them to Quality Department to verify.
2) If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.




Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave 0

Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave 1
Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave 2Acid And Alkali Resistant Air Filter Metal Mesh Plain Weave 3
