0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438

0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438

  • 0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438
  • 0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438
0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-54-4
Payment & Shipping Terms:
Minimum Order Quantity: 10 rolls
Price: Negotiable
Packaging Details: Woven bag
Delivery Time: 3-5 work days
Payment Terms: L/C, T/T
Supply Ability: 5000 Kilogram/Kilograms per Week
Contact Now
Detailed Product Description
Product Name: Air Filter Mesh After Warranty Service: Video Technical Support
Thickness: 0.3-2mm Hole Size (mm): 7*12, 5*10, 10*12
Roll Size: 1M * 20 M/roll Packing: Woven Bag
Short Way Of Mesh: 2-40mm Surface Treatment: Galvanized Plated
Material: Galvanized Steel Wire, Aluminum Sheet, Galvanized Steel Application: Component Of Filter, Supporting And Protection
High Light:

2mm Air Filter Mesh


0.3mm Air Filter Mesh


DIN53438 galvanised welded wire mesh

Gold Supplier Air Filters Outer Wire Mesh Expanded Metal Mesh


1. Product introduction

1)Material: Aluminum ,galvanized sheet, stainless steel wire mesh, copper mesh
2)Pattern: Opening in the shape of diamond, hexagonal or special shape.
3)Features: The expanded metal mesh is strong and durable, with pleasing appearance in its shapes.

4)Sizes: Long way of mesh: 3-100mm ;
Short way of mesh: 2-80mm;
Thickness: 0.3-5mm;


2. Parameter table


LWD(mm) SWD(mm) Strand Width Strand Gauge %Free Area Approx.Kg/m2
6.05 3.38 0.5 0.8 50 2.1
10.24 5.84 0.5 0.8 75 1.2
10.24 5.84 0.9 1.2 65 3.2
3.80 2.10 0.8 0.6 46 2.1
14.20 4.80 1.8 0.9 52 3.3
24.40 7.10 2.4 1.1 57 3.4
23.20 5.80 3.2 1.5 43 6.3
32.70 10.90 3.2 1.5 59 4
33.50 12.40 2.3 1.1 71 2.5
42.90 14.20 4.6 2.7 58 8.6
39.10 18.30 4.7 2.7 60 7.6
43.20 17.08 3.2 1.5 69 3.2
69.80 37.10 5.5 2.1 75 3.9


9. FAQ


2.Payment terms:
50% deposit upon getting the order,balance against the B/L copy.
3.Delivery date:
About 7 working days(≤500pcs), special order is negotiable to be quicker.
4.Sample Terms:
We can supply 1-2 small samples for tree but express cost is covered by your side.
5.Minimum Order Quantity:
No strict principle for standard sizes,but 50pcs for non-standard dimensions or types.
6.Price Terms:
EX-WORKS, FOB, CNF, CIF OR DDU is available and up to you.
7.Lead time:
3 Days for a 40ft container, weeks for two 40ft container.


13. company introduction


Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.
The main products are: air filter equipment and all filter raw materials. Air filter, end cover, glue, filter paper, filter screen, rubber filter ring, rubber filter end cover mold, frame, filter equipment and other models are complete, high quality.

The filter performance of automatic filter is high (good cleaning effect), automatic calorimeter (large capture quantity). It has long oscillation and high durability, which will not cause dust leakage. Water resistance, no blocking air entry, easy and light loading and unloading. In addition, there are screen deep processing filter products, oil and fuel engineering machine finished filter, petroleum ore screen pipe and other screen products.

The company's products are sold to Russia, Britain, Africa, Australia and Southeast Asia and the Middle East and many other countries, well received by customers. Our company has a complete and scientific quality management system.

The products are of good quality and various specifications. We uphold the business philosophy of "honesty, good quality, customer first", and in the spirit of mutual benefit, we are willing to establish good business relations with businesses all over the world. In the face of increasingly fierce market competition, the company carries out all staff training, cultivates talents, changes ideas, improves, strengthens cultivation, adjusts strategies, transforms local advantages into the core competitiveness of survival first and development later, so as to maintain a stable development momentum and meet challenges in the new century. Anping Changfeng filter material Co., Ltd. is recognized by customers for its integrity, strength and product quality. We should be responsible for every customer and every product.
Hebei Anping Changfeng Co., Ltd. is located in No.5 filter material city, Anping County, Hebei Province, which is "the hometown of China international silk screen". It is adjacent to Beijing, Tianjin, Shijiazhuang, Baoding, Hengshui and other large and medium-sized cities, with superior geographical location and developed transportation and logistics. It is 250 kilometers away from Beijing Capital Airport and 200 kilometers away from Tianjin port. Welcome friends from all over the world to visit, guide and business negotiation. We will serve you wholeheartedly.
0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438 00.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438 10.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438 2
0.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438 30.3-2mm Air Filter Mesh , galvanised welded wire mesh DIN53438 4
