20mm Dia Filter End Caps Dust Removal Filter Element Filter Material

Product Details:

Place of Origin:	An Ping China
Brand Name:	Chang Feng
Certification:	ISO9001
Model Number:	9057-05-86

Payment & Shipping Terms:

Minimum Order Quantity:	10 / set
Price:	Negotiable
Packaging Details:	covers' packaging: 1.Plastic sheets inside 2.PP Woven bag outside 3.According to your requiry
Delivery Time:	8-10 work days
Payment Terms:	L/C, T/T
Supply Ability:	5000 Set/Sets per Week filter end caps 5000 sets/week

Contact Now

Detailed Product Description

Product Name:	Filter End Caps	Brand Name:	Chang Feng
Certifications:	ISO 9001	Delivery Time:	Winthin 8 Days
Core Components:	Rubber Mat, Filter Mesh	Thickness:	0.30 Mm To 3.00 Mm, Or Customized
Outer Diameter:	20.00 Mm To 1000 Mm, Or Customized	Packing:	Poly Bag/Piece Or Customized
Materials:	Galvanized, Anti-fingerprint	Types:	Open/closed, With/without Holes, Customized
High Light:	20mm filter end caps , dust removal filter end caps , 20mm air filter caps

Round Cover Of Fingerprint Resistant And Corrosion-Resistant Dust Removal Filter Element

1. Product Description

The filter end cap is mainly used to seal both ends of the filter material and support the filter material to effectively improve the bearing capacity of the filter material. Chang Feng has been specialized in metal filter end caps since 1996 with a wide range of existing molds for air filter end caps for the cartridge filter. We are able to advise customers on the best material proper thickness opt for.Welcome, where we can communicate with each other, learn from each other!

2. Specifications

There are parts of specifications of filter caps we made for clients before for your reference. If you need other shapes, we could make customization.

Open Round End Cap with Tri-Bolt Holes
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.5	215.9
Inner height	0.54	13.716
Outer height	0.5	12.7
Inner rim diameter	6.75	171.45
Open Round End Cap with Outer Lip
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.5	215.9
Inner diameter	0.625	15.875
Outer height	0.368	9.3472
Lip	0.375	9.525

3. Applications

Filter covers are widely used for dust filter, air filter, oil filter, fuel filter, activated carbon filter cartridges.

·Pharmaceutical industry: pre filtration of various antibiotics and other pharmaceutical solutions

·Food and beverage industry: filtration of alcohol, mineral water and drinking water

·Petroleum Industry: oilfield water injection filtration

·Electronic industry: high purity water pre filtration

·Chemical industry: filtration of various organic solvents, acids and lyes

Metallurgical Industry: it is used for the filtration of hydraulic system of rolling mill and continuous caster and the filtration of various lubricating equipment.

4. Product advantage

1.25 years' experience in producing filter end caps.
2. Accurate size according to customer requirements
3. Ensure the filters have a longer life with excellent heat and chemical resistance.
4. Effectively improve the capacity of the filter material.
5. Various exist mold to save your cost.
6. Qualified raw materials with certifications to make the filter caps.

5. Characteristics

Materials: galvanized steel, stainless steel, fingerprint proof, copper / brass, etc
Thickness 0.30 mm to 3.00 mm
Outer diameter 20.00 mm to 1000 mm
Type on / off, with / without holes, customized
Delivery time according to customer requirements
Packaging plastic bag / piece or customized
