High Efficiency Hepa Filter Paper Dust Collection Meltblown

High Efficiency Hepa Filter Paper Dust Collection Meltblown

  • High Efficiency Hepa Filter Paper Dust Collection Meltblown
  • High Efficiency Hepa Filter Paper Dust Collection Meltblown
High Efficiency Hepa Filter Paper Dust Collection Meltblown
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-55-28
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Kilogram/Kilograms(Min. Order)
Price: Negotiable
Packaging Details: Vacuum Cleaner Cooking Oil The Truck Air Filter Paper 1,Inner Packing:Plastic Film 2,Middle Packing:Craft Paper 3,Outer Packing:Plastic Film 4,top and bottom Packing:Paper pallet 5,20ft can load 5.5-6 tons 6,40HQ can load 13.5-16 tons (110 g Hepa Roll Filt
Delivery Time: 1 - 5000 Est. Time15(days)
Payment Terms: L/C, T/T
Supply Ability: 30 Ton/Tons per Quarter
Contact Now
Detailed Product Description
Product Name: HEPA Filter Paper Material: PET、PP
Efficiency: 99.99% Type: Efficient
Marketing Type: New Product 2020 Frame Material: Aluminum,Wooden, Stainless Steel
Suitable: Air, Dust, Sterilization, Odor, Toluene Core Components: Filter Media, Nanofiber, Wood Pulp Paper
Performance: Acid Resistance, Alkali Resistance, High Temperature Resistance, Anti-static Applicable Industries: Painting Factory,spray Workshop, Automotive Factory
High Light:

high efficiency hepa filter paper


dust collection hepa filter paper


meltblown hepa paper

HEPA Filter Paper Double-Effect Composite Plate Filter Filter Paper HEPA Filter Paper


1.Product introduction


Filter paper is a kind of paper with good filtration performance. The paper is loose and has strong absorption property to liquid. Filter paper is often used as the filter medium in analytical laboratories to separate the solution from the solid.

A separator high-efficiency filter is typically sealed using a sealant, so that the sealing of the filter is guaranteed. At the time of installation, since the glass fiber paper is relatively fragile, do not encounter a relatively hard item during installation and use, the glass fiber paper should try to avoid water during use, otherwise it will affect normal use. At the same time it also has interception.


2. Parameter table


No minal size Actual size Thickness Protective net Rated air volume surface air speed Rated initial resistance
(inch) (mm) (mm)   (m3h) (mls) (Pa)
WxHxD W×H×D         H13 H14 u15 u16
2×2 570×570 50 Double-sided protective net 367 0.35 108 115 135 148
2×4 1170x570 50 Double-sided protective net 775 0.35 1o8 115 135 148
2×1 610×305 5o Double-sided protective net 20o 0.35 108 115 135 148
  610×610 50 Double-sided protective net 423 0.35 1o8 115 135 148
2.5×2 762x610 5o Double-sided protective net 535 0.35 108 115 135 148
3x2 915×610 50 Double-sided protective net 646 0.35 1o8 115 135 148
4×3 1170×870 50 Double-sided protective net 1206 0.35 108 115 135 148
4x4 1170×1170(with 5o Double-sided protective net 1637 0.35 108 115 135 148
  570×570 70 Double-sided protective net 472 0.45 1oo 11o 125 140
4×2 1170×570 7o Double-sided protective net 1oo0 0.45 1oo 11o 125 14o
2×1 610×305 7o Double-sided protective net 258 0.45 1oo 11o 125 140
2×2 610×610 7o Double-sided protective net 545 0.45 1oo 11o 125 14o


3. Application


1. High-efficiency filter paper is made of glass fiber as the main raw material and is made by wet molding process.

2.It has the characteristics of uniform fiber distribution, large dust holding capacity, low resistance and high strength. It is an ideal air filter material.
3.Glass fiber filter paper for high efficiency filter (HEPA): mainly used in clean rooms or workbenches of grade 10,000 to grade 100,000, exhaust air of nuclear power plants, high-end household vacuum cleaners, air purifiers, gas masks, etc.

4.Glass fiber filter paper (ULPA) for ultra-efficient air filter: mainly used in chip factories and 100-level, 10-level, 1-level clean workshops, etc.

5.Filter paper is a kind of scientific appliance, it can be an effective filter medium, and filter paper has been widely used in various fields. Depending on the type of fiber that composes the filter paper, the performance and use of the filter paper are different. There are ordinary filter papers used in general occasions, glass fiber filter papers used at high temperatures, and ultra-clean polypropylene filter papers. Paint filter paper is also called V-type dry filter paper, organ spray cabinet filter, paint mist filter paper (folding filter cardboard). It is a new type of environmentally friendly product used in dry spray booths. It uses environmentally friendly filter paper; it no longer has water and no pollution in the spray/paint! It can effectively filter paint, oil, glass materials, and environmental protection. Oxygen resin, asphalt, Teflon, liquefied workpieces, plastics, porcelain, dyes, coatings.


4.Product advantages


1. High filtration precision and high efficiency. The combination of polyester fiber and polymer membrane is adopted. The selected filter material can meet the accuracy requirements specified by users.

2. With large tensile strength and small coefficient of variation, advanced mesh forming technology and forming reinforcement are adopted to enhance and stabilize the tensile strength and maintain the consistency between the initial strength and the strength.

3.The tensile strength is large and the coefficient of variation is small. The advanced meshing technology and forming reinforcement are adopted to make the tensile strength strong and stable, and keep the initial strength and the use strength consistent.

4.With high compressive strength and low coefficient of variation, the selected meshing processing technology and the reinforcement of the formed structure make the compressive strength super strong and stable, and maintain the application of the original super strength and the applied compressive strength.


5. company introduction


Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.

The main products are: air filter equipment and all filter raw materials. Air filter, end cover, glue, filter paper, filter screen, rubber filter ring, rubber filter end cover mold, frame, filter equipment and other models are complete, high quality. The filter performance of automatic filter is high (good cleaning effect), automatic calorimeter (large capture quantity). It has long oscillation and high durability, which will not cause dust leakage. Water resistance, no blocking air entry, easy and light loading and unloading. In addition, there are screen deep processing filter products, oil and fuel engineering machine finished filter, petroleum ore screen pipe and other screen products. The company's products are sold to Russia, Britain, Africa, Australia and Southeast Asia and the Middle East and many other countries, well received by customers. Our company has a complete and scientific quality management system. The products are of good quality and various specifications. We uphold the business philosophy of "honesty, good quality, customer first", and in the spirit of mutual benefit, we are willing to establish good business relations with businesses all over the world. In the face of increasingly fierce market competition, the company carries out all staff training, cultivates talents, changes ideas, improves, strengthens cultivation, adjusts strategies, transforms local advantages into the core competitiveness of survival first and development later, so as to maintain a stable development momentum and meet challenges in the new century. Anping Changfeng filter material Co., Ltd. is recognized by customers for its integrity, strength and product quality. We should be responsible for every customer and every product.


6. FAQ


1.Q:Can you provide free samples?
A:Sorry, Free samples are not available. But after you place the order, samples cost would be return. Which is "FREE" in some way.

2. Q: Can you give me a discount price?
A: It is depending on the volume. The larger the volume is, the more discount you can enjoy.


3.Q:How do you guarantee your quality ?
A: Our workers and technical employees are with many years experiences to ensure the products are good. After production finished,check will be made by quality inspector.


4. Q:How can you guarantee the quality of mass production is same with the sample sent to me before?
A: Our warehouse staff will leave another same sample in our company, with your company name marked on it, which our production will be based on.


5. Q: How can you deal with quality issues that customers feedback after receiving the goods?
A: We will follow below steps to solve the quality issues the may occur.
1) Customers take photos of unqualified goods and then our sales staff will send them to Quality Department to verify.
2) If the issue is confirmed, our sales staff will explain the root cause and take corrective actions in coming orders.
