Air Purifier Hepa Filter Fabric Low Resistance Anti Static

Air Purifier Hepa Filter Fabric Low Resistance Anti Static

  • Air Purifier Hepa Filter Fabric Low Resistance Anti Static
  • Air Purifier Hepa Filter Fabric Low Resistance Anti Static
Air Purifier Hepa Filter Fabric Low Resistance Anti Static
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-55-24
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Kilogram/Kilograms(Min. Order)
Price: Negotiable
Packaging Details: Vacuum Cleaner Cooking Oil The Truck Air Filter Paper 1,Inner Packing:Plastic Film 2,Middle Packing:Craft Paper 3,Outer Packing:Plastic Film 4,top and bottom Packing:Paper pallet 5,20ft can load 5.5-6 tons 6,40HQ can load 13.5-16 tons (110 g Hepa Roll Filt
Delivery Time: 1 - 5000 Est. Time15(days)
Payment Terms: L/C, T/T
Supply Ability: 30 Ton/Tons per Quarter
Contact Now
Detailed Product Description
Product Name: HEPA Filter Paper Custom Processing: Yes
Filter Cloth Type: Complex Effect: High Efficient
Suitable: Air, Dust, PM2.5 Payment Trems: T/T,L/C.,western Union
Color: White, Blue, Purple, Etc. Warranty: Unavailable, Non -quality Problem
Frame Material: Aluminum,Wooden, Stainless Steel Performance: High Temperature And Corrosion Resistance
High Light:

air purifier hepa filter fabric


low resistance hepa filter fabric


anti static hepa filter paper

Air Purifier Filter Paper With High Efficiency And Low Resistance HEPA Filter Paper


1.Product introduction


Filter paper can remove harmful dust, smoke, poison, etc. from gas, and separate impurity particles from liquid; it can also block bacteria and microorganisms. It can also be divided into air filter paper and liquid filter paper in terms of use. High-efficiency filter paper is made of glass fiber as the main raw material and is made by wet molding process. It has the characteristics of uniform fiber distribution, large dust holding capacity, low resistance and high strength. It is an ideal air filter material.


2. Parameter table


No minal size Actual size Thickness Protective net Rated air volume surface air speed Rated initial resistance
(inch) (mm) (mm)   (m3h) (mls) (Pa)
WxHxD W×H×D         H13 H14 u15 u16
2×2 570×570 50 Double-sided protective net 367 0.35 108 115 135 148
2×4 1170x570 50 Double-sided protective net 775 0.35 1o8 115 135 148
2×1 610×305 5o Double-sided protective net 20o 0.35 108 115 135 148
  610×610 50 Double-sided protective net 423 0.35 1o8 115 135 148
2.5×2 762x610 5o Double-sided protective net 535 0.35 108 115 135 148
3x2 915×610 50 Double-sided protective net 646 0.35 1o8 115 135 148
4×3 1170×870 50 Double-sided protective net 1206 0.35 108 115 135 148
4x4 1170×1170(with 5o Double-sided protective net 1637 0.35 108 115 135 148
  570×570 70 Double-sided protective net 472 0.45 1oo 11o 125 140
4×2 1170×570 7o Double-sided protective net 1oo0 0.45 1oo 11o 125 14o
2×1 610×305 7o Double-sided protective net 258 0.45 1oo 11o 125 140
2×2 610×610 7o Double-sided protective net 545 0.45 1oo 11o 125 14o


3. Application


The use of glass fiber wool is generally used for coarse dust filtering dry spray booths in air conditioning systems, and exhaust systems in automobile spray booths to reduce environmental pollution and protect the environment. The product is made of fiberglass in a fluffy state. Therefore, it has a large dust holding capacity and a long service life, and is an excellent material for primary air filtration.


4.Factors Affecting Filtering Effectiveness


There are many factors affecting the efficiency of fiber filter paper, the main ones are particle diameter, fiber thickness, filtration speed and filling rate, as well as temperature, humidity, pressure, dust holding capacity, etc.


5. company introduction


Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.



Air Purifier Hepa Filter Fabric Low Resistance Anti Static 0Air Purifier Hepa Filter Fabric Low Resistance Anti Static 1Air Purifier Hepa Filter Fabric Low Resistance Anti Static 2
