Glass Fiber Hepa Filter Paper Low Resistance And High Strength

Product Details:

Place of Origin:	An Ping China
Brand Name:	chang feng
Certification:	ISO9001
Model Number:	9009-55-3

Payment & Shipping Terms:

Minimum Order Quantity:	1000 Kilogram/Kilograms(Min. Order)
Price:	Negotiable
Packaging Details:	Vacuum Cleaner Cooking Oil The Truck Air Filter Paper 1,Inner Packing:Plastic Film 2,Middle Packing:Craft Paper 3,Outer Packing:Plastic Film 4,top and bottom Packing:Paper pallet 5,20ft can load 5.5-6 tons 6,40HQ can load 13.5-16 tons (110 g Hepa Roll Filt
Delivery Time:	1 - 5000 Est. Time15(days)
Payment Terms:	L/C, T/T
Supply Ability:	30 Ton/Tons per Quarter

Contact Now

Detailed Product Description

Product Name:	Hepa Air Filter	After Warranty Service:	Online Support
Air Permeabiliry:	270-800L/m2.s	Resin Content:	28%
Bursting Strength:	380 Kpa	Stiffness:	3.0mNm
Certification:	ISO9001	Place Of Origin:	Hebei, China
Payment Trems:	T/T,L/C.,western Union	Application:	Air Filtration, Gas Filtration
High Light:	glass fiber hepa filter paper , hepa filter paper low resistance , high strength hepa filter material

Glass Fiber With Low Resistance And High Strength HEPA Filter Paper

1. Product introduction

The high efficiency filter is mainly used for environmental air purification. Its feature is to have high efficiency air filtration. It is small, which can accommodate many pollutants, with a more uniform wind speed, large air volume.

2. Parameter table

No minal size	Actual size	Thickness	Protective net	Rated air volume	surface air speed	Rated initial resistance


(inch)	(mm)	(mm)		(m3h)	(mls)		(Pa)
WxHxD	W×H×D						H13	H14	u15	u16
2×2	570×570	50	Double-sided protective net	367	0.35		108	115	135	148

2×4	1170x570	50	Double-sided protective net	775	0.35		1o8	115	135	148

2×1	610×305	5o	Double-sided protective net	20o	0.35		108	115	135	148

	610×610	50	Double-sided protective net	423	0.35	1o8		115	135	148

2.5×2	762x610	5o	Double-sided protective net	535	0.35	108		115	135	148

3x2	915×610	50	Double-sided protective net	646	0.35	1o8		115	135	148

4×3	1170×870	50	Double-sided protective net	1206	0.35	108		115	135	148

4x4	1170×1170(with	5o	Double-sided protective net	1637	0.35	108		115	135	148
	ribs)
	570×570	70	Double-sided protective net	472	0.45	1oo		11o	125	140

4×2	1170×570	7o	Double-sided protective net	1oo0	0.45	1oo		11o	125	14o

2×1	610×305	7o	Double-sided protective net	258	0.45	1oo		11o	125	140

2×2	610×610	7o	Double-sided protective net	545	0.45	1oo		11o	125	14o

3. Technology

Filter paper is generally made of pure cotton linters, which has good filtration and absorption performance and generally high compressive strength. It is suitable for filtering some industrial organic oils and chemical and pharmaceutical organics, etc., to separate solid and semi-solid impurities. . They are all made by machines, and paper is made by machines, otherwise it would not be possible to meet such a huge amount of use in people's daily lives. However, there must be a large-capacity machine for compounding, and then through temperature control, it is rolled by a pressing machine.

4. Service

1. Making the sample until you are satisfied with it.

2. Providing production schedule photos to ensure you know every process.

3. Offering professional one-on-one service and replying your E-mail within three hours

4. Shipment sample for checking before shipment.

5. Priority to get the our latest product information after our cooperation

5. Matters Needing Attention

The filter paper installation is correct, the filter paper must be dried, and there should be no damage. Before operation, the punched paper is carefully sandwiched between each filter plate and filter box. The quantity of filter paper is usually 2 ~ 4 sheets, depending on the requirements and quality of filter paper
