Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable

Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable

  • Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable
  • Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable
Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-58-8
Payment & Shipping Terms:
Minimum Order Quantity: 10 rolls
Price: Negotiable
Packaging Details: Woven bag
Delivery Time: 3-5 work days
Payment Terms: L/C, T/T
Supply Ability: 5000 Kilogram/Kilograms per Week
Contact Now
Detailed Product Description
Product Name: Air Filters Material Surface Treatment: Alloy
MOQ: 20 Rolls Machinery Test Report: Provided
Packing: Woven Bag Warranty Of Core Components: Not Available
Roll Size: 1M * 20 M/roll Hole Size (mm): 7*12, 5*10, 10*12
Plate Thickness (mm): 0.35/ 0.4/ 0.5/ 0.6/0.8 Use: Emulsion ReGeneration, Waste Oil Filtration And Treatment Of Continuous Casting Water System In Metallurgical Industry
Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory Application: Component Of Filter, Supporting And Protection
High Light:

Uniform Pores Air Filters Material

,

Reusable Alloy Air Filters Material

,

Barrel Ac Filter Material



Uniform Pores And Reusable Alloy Filter Screen Barrel Air Filters Material



1. Product introduction

After the stainless steel filter cartridge is put into market use, it is generally welcomed by people, mainly because it has the following characteristics: the specific structure determines that it can be cleaned and used repeatedly after a period of time, so as to save cost. According to the size required, it can be produced into various specifications and styles, with wide use, sensitivity and convenience, and many device modes. It can bear large working pressure, small pressure loss, low operation cost and good energy-saving effect. Large processing capacity, small volume and large pollution capacity. Things with large flow can greatly save man hours.

2. Parameter table



Thickness Strand Width Hole Size Note
2mm 5mm 25×50mm In Panel
Big Hole
2.5mm 5mm 30×60mm
3mm 5-10mm 40×80mm
2-3mm 5-15mm 50×100mm
3mm 20-30mm 90×200mm
3mm 20-30mm 100×250mm

0.8mm 1.5mm 5×10mm In Roll
Small Hole

0.3-1.5mm 0.3-2.5mm (2-15)mm×(3-30)mm
as you need as you need 2×3
as you need as you need 3×4
as you need as you need 4×5
as you need as you need 4×6
EXPENDED FLATTENED MESH
LWD(mm) SWD(mm) Strand Width Strand Gauge %Free Area Approx.Kg/m2
6.05 3.38 0.5 0.8 50 2.1
10.24 5.84 0.5 0.8 75 1.2
10.24 5.84 0.9 1.2 65 3.2
3.80 2.10 0.8 0.6 46 2.1
14.20 4.80 1.8 0.9 52 3.3
24.40 7.10 2.4 1.1 57 3.4
23.20 5.80 3.2 1.5 43 6.3
32.70 10.90 3.2 1.5 59 4
33.50 12.40 2.3 1.1 71 2.5
42.90 14.20 4.6 2.7 58 8.6
39.10 18.30 4.7 2.7 60 7.6
43.20 17.08 3.2 1.5 69 3.2
69.80 37.10 5.5 2.1 75 3.9



3. company introduction



Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.
The main products are: air filter equipment and all filter raw materials. Air filter, end cover, glue, filter paper, filter screen, rubber filter ring, rubber filter end cover mold, frame, filter equipment and other models are complete, high quality. The filter performance of automatic filter is high (good cleaning effect), automatic calorimeter (large capture quantity). It has long oscillation and high durability, which will not cause dust leakage. Water resistance, no blocking air entry, easy and light loading and unloading. In addition, there are screen deep processing filter products, oil and fuel engineering machine finished filter, petroleum ore screen pipe and other screen products. The company's products are sold to Russia, Britain, Africa, Australia and Southeast Asia and the Middle East and many other countries, well received by customers. Our company has a complete and scientific quality management system. The products are of good quality and various specifications. We uphold the business philosophy of "honesty, good quality, customer first", and in the spirit of mutual benefit, we are willing to establish good business relations with businesses all over the world. In the face of increasingly fierce market competition, the company carries out all staff training, cultivates talents, changes ideas, improves, strengthens cultivation, adjusts strategies, transforms local advantages into the core competitiveness of survival first and development later, so as to maintain a stable development momentum and meet challenges in the new century. Anping Changfeng filter material Co., Ltd. is recognized by customers for its integrity, strength and product quality. We should be responsible for every customer and every product.
Hebei Anping Changfeng Co., Ltd. is located in No.5 filter material city, Anping County, Hebei Province, which is "the hometown of China international silk screen". It is adjacent to Beijing, Tianjin, Shijiazhuang, Baoding, Hengshui and other large and medium-sized cities, with superior geographical location and developed transportation and logistics. It is 250 kilometers away from Beijing Capital Airport and 200 kilometers away from Tianjin port. Welcome friends from all over the world to visit, guide and business negotiation. We will serve you wholeheartedly.





4. Product Usage



 Application of stainless steel filter cartridge: petrochemical and oilfield pipeline filtration; Fuel filtration of refueling equipment and engineering machinery equipment; Filtration equipment in water treatment industry; Pharmaceutical and food processing. Such as industrial wastewater, circulating water filtration, emulsion regeneration, waste oil filtration treatment, continuous casting water system and blast furnace water system in metallurgical industry, high-pressure water descaling system for hot rolling. It is an advanced, efficient and easy to operate automatic filtering device. The filter is composed of a simplified body, a stainless steel filter screen, a sewage discharge part, a transmission device and an electrical control part. Stainless steel filter cartridge, its overall dimension and filtration accuracy are produced according to customer requirements.






Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable 0Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable 1Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable 2
Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable 3Uniform Pores Alloy Filter Screen Barrel Air Filters Material Reusable 4
