Place of Origin: | An Ping China |
Brand Name: | Chang Feng |
Certification: | ISO9001 |
Model Number: | 9009-54-4 |
Minimum Order Quantity: | 10 rolls |
---|---|
Price: | Negotiable |
Packaging Details: | Woven bag |
Delivery Time: | 3-5 work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 5000 Kilogram/Kilograms per Week |
Product Name: | Air Filter Mesh | Condition: | New |
---|---|---|---|
After Warranty Service: | Video Technical Support | Showroom Location: | None |
Machinery Test Report: | Provided | Warranty Of Core Components: | Not Available |
Material: | Carbon Steel | Hole Size (mm): | 7*12, 5*10, 10*12 |
Roll Size: | 1M * 20 M/roll | Packing: | Woven Bag |
Plate Thickness (mm): | 0.35/ 0.4/ 0.5/ 0.6 | Surface Treatment: | Galvanized Plated |
MOQ: | 20 Rolls | Use: | Filter |
Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory | Application: | Component Of Filter, Supporting And Protection |
High Light: | expanded air filter mesh fabric,0.6mm Air Filters Material,1M * 20 M/Roll Air Filters Material |
1)Material: Aluminum ,galvanized sheet, stainless steel wire mesh, copper mesh
2)Pattern: Opening in the shape of diamond, hexagonal or special shape.
3)Features: The expanded metal mesh is strong and durable, with pleasing appearance in its shapes.
4)Sizes: Long way of mesh: 3-100mm ;
Short way of mesh: 2-80mm;
Thickness: 0.3-5mm;
We can supply most products in coils of up to 100 metres long to a width tolerance of +/- 0.20mm for slit coil, or +/- 0.50mm without slitting.
Coils can be ordered in any width between 500mm and 1250mm. This allows customers to purchase exactly the finished size needed and minimise waste.
Thickness | Strand Width | Hole Size | Note | |||
2mm | 5mm | 25×50mm | In Panel Big Hole |
|||
2.5mm | 5mm | 30×60mm | ||||
3mm | 5-10mm | 40×80mm | ||||
2-3mm | 5-15mm | 50×100mm | ||||
3mm | 20-30mm | 90×200mm | ||||
3mm | 20-30mm | 100×250mm | ||||
0.8mm | 1.5mm | 5×10mm | In Roll Small Hole |
|||
0.3-1.5mm | 0.3-2.5mm | (2-15)mm×(3-30)mm | ||||
as you need | as you need | 2×3 | ||||
as you need | as you need | 3×4 | ||||
as you need | as you need | 4×5 | ||||
as you need | as you need | 4×6 |
EXPENDED FLATTENED MESH | |||||
LWD(mm) | SWD(mm) | Strand Width | Strand Gauge | %Free Area | Approx.Kg/m2 |
6.05 | 3.38 | 0.5 | 0.8 | 50 | 2.1 |
10.24 | 5.84 | 0.5 | 0.8 | 75 | 1.2 |
10.24 | 5.84 | 0.9 | 1.2 | 65 | 3.2 |
3.80 | 2.10 | 0.8 | 0.6 | 46 | 2.1 |
14.20 | 4.80 | 1.8 | 0.9 | 52 | 3.3 |
24.40 | 7.10 | 2.4 | 1.1 | 57 | 3.4 |
23.20 | 5.80 | 3.2 | 1.5 | 43 | 6.3 |
32.70 | 10.90 | 3.2 | 1.5 | 59 | 4 |
33.50 | 12.40 | 2.3 | 1.1 | 71 | 2.5 |
42.90 | 14.20 | 4.6 | 2.7 | 58 | 8.6 |
39.10 | 18.30 | 4.7 | 2.7 | 60 | 7.6 |
43.20 | 17.08 | 3.2 | 1.5 | 69 | 3.2 |
69.80 | 37.10 | 5.5 | 2.1 | 75 | 3.9 |
Hebei Anping Changfeng filter material Co., Ltd. is a solid factory for 25 years. Our company is a modern enterprise which produces and sells filter core raw materials, filter equipment and screen deep processing filter industry. After 25 years of efforts, it has gradually developed and expanded, with more than 300 engineers, technicians and workers. Our factory covers an area of 30 mu. 4 large workshops of 1000 square meters, two workshops of 500 square meters, with 30 press, 12 CNC punch machines, hydraulic press and lathe and other filter equipment welding machines.
The main products are: air filter equipment and all filter raw materials. Air filter, end cover, glue, filter paper, filter screen, rubber filter ring, rubber filter end cover mold, frame, filter equipment and other models are complete, high quality. The filter performance of automatic filter is high (good cleaning effect), automatic calorimeter (large capture quantity). It has long oscillation and high durability, which will not cause dust leakage. Water resistance, no blocking air entry, easy and light loading and unloading. In addition, there are screen deep processing filter products, oil and fuel engineering machine finished filter, petroleum ore screen pipe and other screen products. The company's products are sold to Russia, Britain, Africa, Australia and Southeast Asia and the Middle East and many other countries, well received by customers. Our company has a complete and scientific quality management system. The products are of good quality and various specifications. We uphold the business philosophy of "honesty, good quality, customer first", and in the spirit of mutual benefit, we are willing to establish good business relations with businesses all over the world. In the face of increasingly fierce market competition, the company carries out all staff training, cultivates talents, changes ideas, improves, strengthens cultivation, adjusts strategies, transforms local advantages into the core competitiveness of survival first and development later, so as to maintain a stable development momentum and meet challenges in the new century. Anping Changfeng filter material Co., Ltd. is recognized by customers for its integrity, strength and product quality. We should be responsible for every customer and every product.
Hebei Anping Changfeng Co., Ltd. is located in No.5 filter material city, Anping County, Hebei Province, which is "the hometown of China international silk screen". It is adjacent to Beijing, Tianjin, Shijiazhuang, Baoding, Hengshui and other large and medium-sized cities, with superior geographical location and developed transportation and logistics. It is 250 kilometers away from Beijing Capital Airport and 200 kilometers away from Tianjin port. Welcome friends from all over the world to visit, guide and business negotiation. We will serve you wholeheartedly.
