Ethylene Propylene Diene Monomer Rubber Air Filter Seal
1. Specification parameters
Rubber Seal can produce solid rubber strip, hollow rubber strip, conductive rubber strip, foam rubber strip and special-shaped rubber strip of the following materials. Different cross-section structures can be designed according to the parts and conditions of use. Most customers are generally made of chloroprene rubber, ethylene propylene diene monomer rubber, silicone rubber and other rubber materials with excellent aging resistance due to the requirements of UV aging resistance and ozone resistance. Of course, we also have the ability to produce garlast? Ffkm perfluorinated rubber products. Our manufacturing methods are extrusion continuous vulcanization, extrusion vulcanization tank vulcanization or molding vulcanization. You can also tell us any geometry you need. Contact the sales personnel of RAST sealing products, and we will send technical personnel to assist you to complete the specified sealing system.
2. Data Sheet
| Product name |
Rubber Seal |
| Type |
O model ,U model,I model |
| Size |
customized |
| Brand Name |
Chang Feng |
| texture of material |
Made of chloroprene rubber, ethylene propylene diene monomer rubber, silicone rubber and other rubber materials |
| working temperature |
-40℃~150℃ |
| hardness |
85~90shore |
| max pressure |
27MPa |
| sample |
free |
| certification |
AQB |
| OEM |
accept |
| capacity |
1000pcs per day |
| color |
Mainly black,Customized according to different colors |
| Square type |
8x8, 10x10, 10x12, 12x12, |
| Triangle type |
8x10, 10x12 |
| Rubber seal: |
In roll / O ring rubber gasket |
3. FAQ
Q: What's the MOQ(Minimum Order Quantity)?
A: All filter products : MOQ = 300 pcs
Q: Could we apply samples?
A: You can easily contact us by E-mail, Skype, or telephone to make further arrangement for our samples.
Q: What's your terms of packing?
A: Covered with PE bags, outer brown carton and we could be customized for your request.
Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q: What are the payment terms?
A: T/T, Western Union, Cash, L/C. First time buyer transaction: Cash Payment or at least 7 days at sight. Please pay some deposit of payment in advance, if payment ≥ 35,000 USD, 30% deposit in advance, balance before shipment.
Q: What is your loading port, terms of delivery and delivery time?
A: 1. Ningbo Port 2. FOB 3. Generally two weeks upon two weeks upon receipts of the deposit. If you have special requirement of delivery, please let us know.
4. Production process
Extrusion vulcanization can vulcanization or molding vulcanization.
Rubber sealing strips can be classified according to section shape, vulcanization method, application position and purpose, material and other methods.
(1) Discontinuous vulcanization method (cut the extruded rubber strip according to a certain length, put it into the vulcanizing tank for vulcanization, and extrude the semi-finished rubber strip
Put it into the model;
(2) Continuous vulcanization (microwave continuous vulcanization, salt bath continuous vulcanization, hot air continuous vulcanization)
In addition, some methods such as chemical method, etc.
Microwave continuous vulcanization composite sealing strip: microwave vulcanization technology is one of the key technologies of foreign energy crisis in 1970s
After the application and widely promoted production technology. Microwave continuous vulcanization technology can not only produce metal core, solid core rubber and sponge
Moreover, it is superior to other continuous vulcanization devices in energy saving and work efficiency improvement.
5. Operation method
Cut the sealing strip to the size you need, then stick it with the special glue for the filter element, and then stick it on the filter element cover with the glue to play an effective sealing role.
