Zinc plated Air Filter Hat 0.5-1.5mm Thickness anti fingerprint

Product Details:

Place of Origin:	An Ping China
Brand Name:	Chang Feng
Certification:	ISO9001
Model Number:	9009-54-86

Payment & Shipping Terms:

Minimum Order Quantity:	10 / set
Price:	Negotiable
Packaging Details:	covers' packaging: 1.Plastic sheets inside 2.PP Woven bag outside 3.According to your requiry
Delivery Time:	8-10 work days
Payment Terms:	L/C, T/T
Supply Ability:	5000 Set/Sets per Week filter end caps 5000 sets/week

Contact Now

Detailed Product Description

Product Name:	Filter End Caps	Thickness:	0.5-1.5
Marketing Type:	New Product 2020	Core Components:	Bearing, Pump
Dimension:	As Your Requirements	Packing Type:	Bags Or Cartons
Weight:	0.1-2kgs, 2-20KG, 750kg, 1-100kg	Material:	Galvanized, Metal, Steel, Anti-fingerprint
Applicable Industries:	Hotels, Garment Shops, Machinery Repair Shops, Food & Beverage Factory, Farms, Retail, Food Shop, Printing Shops, Energy & Mining, Food & Beverage Shops	Surface Treatment:	Zinc-plated/powdered/anti-fingerprint/plastic Spraying Or Else
High Light:	0.5mm air filter hat , Zinc Plated air filter cap , 1.5mm air filter cap

Activated Carbon Round Filter Accessories With Holes Filter End Cover

1. Product Description

The filter end cap is mainly used to seal both ends of the filter material and support the filter material to effectively improve the bearing capacity of the filter material. Chang Feng has been specialized in metal filter end caps since 1996 with a wide range of existing molds for air filter end caps for the cartridge filter. We are able to advise customers on the best material proper thickness opt for. Welcome to contact us to have further discussion.

2. Specifications

There are parts of specifications of filter caps we made for clients before for your reference. If you need other shapes, we could make customization.

Open Round End Cap with Tri-Bolt Holes
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.5	215.9
Inner height	0.54	13.716
Outer height	0.5	12.7
Inner rim diameter	6.75	171.45
Open Round End Cap with Outer Lip
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.5	215.9
Inner diameter	0.625	15.875
Outer height	0.368	9.3472
Lip	0.375	9.525
Open Round End Cap
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.5	215.9
Inner height	0.5	12.7
Outer Height	0.5	12.7
Closed Round End Cap
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.375	212.725
Inner height	0.5	12.7
outer height	0.5	12.7
Closed Round End Cap with Bolt Hole
	Inches	Millimeters
Outer diameter	12.75	323.85
Inner diameter	8.375	212.725
Inner height	0.5	12.7
Outer height	0.5	12.7
Bolt Hole	0.625	15.875
Open Round End Cap with Flange
	Inches	Millimeters
Outer diameter	5.75	146.05
Inner diameter	2.5	63.5
Inner height	0.5	12.7
Outer height	0.278	7.0612
Closed Round End Cap
	Inches	Millimeters
Outer diameter	5.25	133.35
Inner diameter	2.5	63.5
Inner height	0.875	22.225
Outer height	0.172	4.3688

3. Product advantage

25 years' experience in producing filter end caps.
2. Accurate size according to customer requirements
3. Ensure the filters have a longer life with excellent heat and chemical resistance.
4. Effectively improve the capacity of the filter material.
5. Various exist mold to save your cost.
6. Qualified raw materials with certifications to make the filter caps.

4.Service

we can provide a free sample with our catalog. But the courier charge will on your side. We'll send back the courier charge if you make an order.

4. Characteristics

Materials: galvanized steel, stainless steel, fingerprint proof, copper / brass, etc
Thickness 0.30 mm to 3.00 mm
Outer diameter 20.00 mm to 1000 mm
Type on / off, with / without holes, customized
Delivery time according to customer requirements
Packaging plastic bag / piece or customized
It is used in dust catcher, air filter, fuel filter, oil filter, air compressor, water filter, activated carbon filter, etc.
Provide OEM
Quality control ISO certification
After sales service, product testing report, online tracking.
