99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume

99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume

  • 99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume
  • 99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume
99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume
Product Details:
Place of Origin: An Ping China
Brand Name: chang feng
Certification: ISO9001
Model Number: 9009-55-2
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Kilogram/Kilograms(Min. Order)
Price: Negotiable
Packaging Details: Vacuum Cleaner Cooking Oil The Truck Air Filter Paper 1,Inner Packing:Plastic Film 2,Middle Packing:Craft Paper 3,Outer Packing:Plastic Film 4,top and bottom Packing:Paper pallet 5,20ft can load 5.5-6 tons 6,40HQ can load 13.5-16 tons (110 g Hepa Roll Filt
Delivery Time: 1 - 5000 Est. Time15(days)
Payment Terms: L/C, T/T
Supply Ability: 30 Ton/Tons per Quarter
Contact Now
Detailed Product Description
Product Name: Hepa Air Filter After Warranty Service: Online Support
Application: Air Filtration System Bursting Strength: 380 Kpa
Air Permeabiliry: 280-800L/m2.s Resin Content: 27%
Stiffness: 3.0mNm Payment Trems: T/T,L/C.,western Union
Place Of Origin: Hebei, China Certification: ISO9001
High Light:

0.3 Micro hepa paper roll

,

99.97% HEPA Filter Paper

,

367 M3h HEPA Filter Paper

Hepa Air Filter Raw 99.97% High Efficiency 0.3 Micron In Roll For Air Filter

1. Product introduction



This polyester filter media with/without PTFE membrane is made of high quality filament yarn without using any binding agent. It has been widely applied in making pleated dust collection cartridges. This hard finished material is very stable & structurally durable. This unique & hard finished material provides features of good pleatability, high durable, and unique structure of very fine filament yarn which offer high performance in filtration. This filter media with PTFE membrane provides excellent stable structure, fine dust release & good release & good resistance of particle penetration in to the media. This spun bonded polyester filter media are pleated in different pleated depths & height to accommodated desired filtration area.



2. Parameter table



No minal size Actual size Thickness Protective net Rated air volume surface air speed Rated initial resistance
(inch) (mm) (mm)   (m3h) (mls) (Pa)
WxHxD W×H×D         H13 H14 u15 u16
2×2 570×570 50 Double-sided protective net 367 0.35 108 115 135 148
2×4 1170x570 50 Double-sided protective net 775 0.35 1o8 115 135 148
2×1 610×305 5o Double-sided protective net 20o 0.35 108 115 135 148
  610×610 50 Double-sided protective net 423 0.35 1o8 115 135 148
2.5×2 762x610 5o Double-sided protective net 535 0.35 108 115 135 148
3x2 915×610 50 Double-sided protective net 646 0.35 1o8 115 135 148
4×3 1170×870 50 Double-sided protective net 1206 0.35 108 115 135 148
4x4 1170×1170(with 5o Double-sided protective net 1637 0.35 108 115 135 148
ribs)
  570×570 70 Double-sided protective net 472 0.45 1oo 11o 125 140
4×2 1170×570 7o Double-sided protective net 1oo0 0.45 1oo 11o 125 14o
2×1 610×305 7o Double-sided protective net 258 0.45 1oo 11o 125 140
2×2 610×610 7o Double-sided protective net 545 0.45 1oo 11o 125 14o





3. Technology



This polyester filter media with/without PTFE membrane is made of high quality filament yarn without using any binding agent. It has been widely applied in making pleated dust collection cartridges. This hard finished material is very stable & structurally durable. This unique & hard finished material provides features of good pleatability, high durable, and unique structure of very fine filament yarn which offer high performance in filtration. This filter media with PTFE membrane provides excellent stable structure, fine dust release & good release & good resistance of particle penetration in to the media. This spun bonded polyester filter media are pleated in different pleated depths & height to accommodated desired filtration area.



4. Service



1. Making the sample until you are satisfied with it.

2. Providing production schedule photos to ensure you know every process.

3. Offering professional one-on-one service and replying your E-mail within three hours

4. Shipment sample for checking before shipment.

5. Priority to get the our latest product information after our cooperation





99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 0



99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 199.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 299.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 3

99.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 499.97% High Efficiency HEPA Filter Paper 0.3 Micron 367 M3h Air Volume 5
