Whtie Hepa Filter Paper Activated Charcoal Material 2 Kn/M Tensile Strength

Product Details:

Place of Origin:	An Ping China
Brand Name:	Chang Feng
Certification:	ISO9001
Model Number:	9009-5-6

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiable
Packaging Details:	We can design and supply various packaging and labels according to customers' needs (including product printing, inner packaging bags, independent packaging boxes, and external packaging for turnover). In combination with customs regulations for receiving
Delivery Time:	8-10 work days
Payment Terms:	L/C, T/T
Supply Ability:	50000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Product Name:	Hepa Air Filter Paper	Construction:	Panel Filter
Properties:	High Dust Holding Capacity,good Pleating Durability	Dimension(LWH):	7618220 Customizable
After-sales Service Provided:	No After-sales Service, No Overseas Service Provided	Color:	Black, Etc
Filtration Rate:	99.8%	Material:	Activated Carbon
Applicable Industries:	Aviation,marines,heavy-duty Machineries,nuclear Power Stations, Et	Function:	Catch The Dusts And Particles And Absorb The Odor
Type:	Air Purifier And Air Cleaner Filter Replacements	Warranty:	1 Year
High Light:	2 Kn/M activated charcoal filter paper , Activated Charcoal HEPA Filter Paper , 99.8% HEPA Filter Paper

Qualitative Car Board Hepa Air Filter Paper Used In Automotive Filtration

1. Product introduction

Air Filter paper is made from superfine glass fibers as filtration layer, mainly used in hydraulic filter.

It is laminated with synthetic fibers as protection layers on both sides or one side. It has the advantages of high efficiency, high

dust holding capacity, good strength, good pleating durability and stable chemical properties.

2. Parameter table

Model Item	CF-ZSU1	CF-ZSH3	CF-ZSH5	CF-ZS10
Filter Precision (um )	1	2-3	4-6	8-12
ration (±10g/m2 )
duplex	140	140	140	140
air permeability
l/m2.sec	20	50	90	160
resistance
Pa	330	130	85	50
average pore size
um		20	30	40
filtration efficiency(5.3cm/s)
%	99.95	95	80	60
tensile strength
KN/ m	2	2	2	2
thickness
mm	double-faced 0.5±0.1mm
Application	Fuel (diesel, gasoline),Aviation fuel, pharmaceutical, compression, air, chemical industry, compressed air, Oil and gasseparation, hydraulic oil, Lubricating oil and filter, etc

3. Technology

Air filter paper is a key component of the air filter, which determines the performance of the air filter. Air filter paper usually includes a paper filter layer made of ordinary wood pulp as the main component. Because ordinary wood pulp fibers are relatively fine , Low ash capacity, short life and other shortcomings, and the paper air filter paper is not water resistant, and it is easy to deform when the air humidity changes, which will affect the filtering effect.

4. Product principle

Air filter paper is used in the air filter of automobile engine. Its function is to filter out the dust and impurities when the air enters the engine through the filter paper. Therefore, its filtering function ensures the supply of clean air and protects the engine from wear.
