Hebei Changfeng Filter Material Co., Ltd.
One-stop solution for Filter production
Place of Origin: | An Ping China |
Brand Name: | Chang Feng |
Certification: | ISO9001 |
Model Number: | 9009-54-6 |
Minimum Order Quantity: | Negotiable |
---|---|
Price: | Negotiable |
Packaging Details: | carton Negotiable |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, T/T |
Supply Ability: | 2000 Set/Sets per Day |
Product Name: | Air Filter Element | Marketing Type: | NEW Product 2020 |
---|---|---|---|
Core Components: | Cap/Filter Media | Efficiency: | 99.95%.99.5% |
Certification: | ISO9001:2008 | Life: | 1~2Years |
Dimension(L*W*H): | Customizable | Quality: | High-Quality |
Color: | White / Blue / Red / Custom Made | Applicable Lndustries: | Manufacturing Plant,Retail,Energy & Mining |
High Light: | 200oF Air compressor intake filter housing,1 Micron 14 inch air filter element,14 inch air filter element |
1.Product characteristics
(1) Imported cellulose fiber or synthetic fiber for base
media (80%cellulose and 20%polyester).
(2) Excellent filter efficiency.
(3) Wide pleat spacing, great filter surface.
(4) Electrochemical plate top and bottom, no rust.
(5) Perforated zinc galvanized metal inner core, allows good airflow.
(6) Specialty chlorine rubber gasket to ensure airtight sealing.
(7) Applicable temperature: 65°C.
2.Technology
1. Base media: Polyester 20% Cellulose 80%
2. Operating efficiency: 99.9% on 1 micron
3. Washable: Several times
4. Maximum operating temperature: 200oF/93oC
5. Abrasion resistance: Excellent
6. Chemical tolerance: Excellent
7. Optional flame retardant media(FR): To order
3.Parameter table
Model | O.D | I.D | Length | Filtration surface(m2) |
SFF/Z3266 | Φ324mm | Φ213mm | 660mm | 21m2 |
SFF/Z3566 | Φ352mm | Φ241mm | 660mm | 23m2 |
SFF/Z3275 | Φ324mm | Φ213mm | 750mm | 26m2 |
SFF/Z3288 | Φ324mm | Φ213mm | 880mm | 27m2 |
SFF/Z3290 | Φ324mm | Φ213mm | 915mm | 28m2 |
product name: | Air Filter Element | |||
Applicable Lndustries | Manufacturing Plant,Retail,Energy & Mining | |||
Marketing Type | NEW Product 2020 | |||
Core Components | Cap/Filter Media | |||
Efficiency | 99.95%.99.5% | |||
Porosity | 2μ | |||
Brand Name | Chang Feng | |||
Certification |
ISO9001:2008 |
|||
Warranty | 1Year | |||
color | White / Blue / Red / custom made | |||
Filter media | Synthetic Paper | |||
Life | 1~2Years | |||
Frame material | Gavalnized Steel | |||
Construction | Cartridge filter | |||
Place of Origin | Hebei, China | |||
width | 88mm-2000mm/custom made | |||
height | 176mm /custom made | |||
Certification | ISO 9001,AFTL | |||
After-sales Service Provided | Online support,Overseas service center available | |||
shape | Cylindrical Cartidge Filter |
4.Production process
The filters will reduce compressed air power costs, help minimize maintenance expense, and increase overall air system and production line efficiency. It is a known fact that high quality filters improve the efficiency of your air compressor installation. As soon as a filter is installed, the filtration process begins. Over time and depending on the working conditions and environment, this filtration process inevitably results in “pressure drop”. Every psig pressure drop negatively affects power consumption and operating cost; a pressure drop of 6 psig relates to a 3% increase in energy consumption
