10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature

10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature

  • 10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature
  • 10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature
10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature
Product Details:
Place of Origin: An Ping China
Brand Name: Chang Feng
Certification: ISO9001
Model Number: 9009-54-6
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: carton Negotiable
Delivery Time: 5-8 work days
Payment Terms: L/C, T/T
Supply Ability: 2000 Set/Sets per Day
Contact Now
Detailed Product Description
Product Name: Air Filter Element Applicable Lndustries: Manufacturing Plant,Retail,Energy & Mining
Marketing Type: NEW Product 2020 Core Components: Cap/Filter Media
Efficiency: 99.95%.99.5% Porosity: 2μ
Brand Name: Chang Feng Certification: ISO9001:2008
Warranty: 1Year Color: White / Blue / Red / Custom Made
High Light:

1 Micron 10 inch air filter element

,

coalescing filter for air compressor

,

200oF 10 inch air filter element

99.95%Car Air Purification Filter Air Filter Element 65°C



1.Technology



1. Base media: Polyester 20% Cellulose 80%
2. Operating efficiency: 99.9% on 1 micron
3. Washable: Several times
4. Maximum operating temperature: 200oF/93oC
5. Abrasion resistance: Excellent
6. Chemical tolerance: Excellent
7. Optional flame retardant media(FR): To order



2.Product use



Marktets: Thermal spray, welding, mining, chemical processing, metal buffing, pharmaceutical,cement, woodworking and etc.
Dust types: Fumed silica, metallic fume, metallurgical powders, and etc.



3.Parameter table



Model O.D I.D Length Filtration surface(m2)
SFF/Z3266 Φ324mm Φ213mm 660mm 21m2
SFF/Z3566 Φ352mm Φ241mm 660mm 23m2
SFF/Z3275 Φ324mm Φ213mm 750mm 26m2
SFF/Z3288 Φ324mm Φ213mm 880mm 27m2
SFF/Z3290 Φ324mm Φ213mm 915mm 28m2
product name: Air Filter Element
Applicable Lndustries Manufacturing Plant,Retail,Energy & Mining
Marketing Type NEW Product 2020
Core Components Cap/Filter Media
Efficiency 99.95%.99.5%
Porosity 2μ
Brand Name Chang Feng
Certification ISO9001:2008
Warranty 1Year
color White / Blue / Red / custom made
Filter media Synthetic Paper
Life 1~2Years
Frame material Gavalnized Steel
Construction Cartridge filter
Place of Origin Hebei, China
width 88mm-2000mm/custom made
height 176mm /custom made
Certification ISO 9001,AFTL
After-sales Service Provided Online support,Overseas service center available
shape Cylindrical Cartidge Filter





4.Product advantage



(1) Imported cellulose fiber or synthetic fiber for base

media (80%cellulose and 20%polyester).

(2) Excellent filter efficiency.

(3) Wide pleat spacing, great filter surface.

(4) Electrochemical plate top and bottom, no rust.

(5) Perforated zinc galvanized metal inner core, allows good airflow.

(6) Specialty chlorine rubber gasket to ensure airtight sealing.

(7) Applicable temperature: 65°C.



10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature 0

10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature 1

10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature 2

10 Inch Air Filter Element 1 Micron Coalescing 200oF Operating Temperature 3
