316L Stainless Steel Filter Element 2470 pa Bubble Piont Pressure

Product Details:

Place of Origin:	An Ping China
Brand Name:	Chang Feng
Certification:	ISO9001
Model Number:	9009-02-09

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	>=10 Sets $72.00
Packaging Details:	wooden box packing Customized by customer requires
Delivery Time:	10-15 work days 1 - 100 Set
Payment Terms:	L/C, T/T
Supply Ability:	500 Set/Sets per Month

Contact Now

Detailed Product Description

Product Name:	Stainless Steel Filter Element	Application:	Kinds Filtration Industry
Certificate:	ISO9001	Sample:	Avaliable Sample
Packing:	Wooden Cases	Applicable Industries:	Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Energy & Mining
Local Service Location:	Local Service Location:	Length:	Customer Order
OD:	Customer Order	We Are Facto：ry:	20 Years Experience
High Light:	ISO9001 fine mesh screen filter , 2470 pa Stainless Steel Filter Element , 316L Stainless Steel Filter Element

Punching; Metal Wire Mesh Circle; Cylindrical Filter; Smooth And Bright Stainless Steel Material

1. Product introduction

There are many kinds of filter cartridge materials, depending on customer needs to customize production;
304, 304L, 316, 316L, used to make stainless steel wire mesh, perforated metal wire mesh,
welded wire mesh, copper wire mesh and aluminum wire mesh.

2. Parameter table

Absolute Filter Rating	Bubble Piont Pressure	Average Air Permeability	Thichness	Weight	Porosity	Dirt Holding Capacity
(渭)	(Pa)	(l/dm2/min)	(mm)	(g/m2)	(%)	(mg/cm2)
3	12300	9	0.35	975	65	6.4
5	7600	34	0.34	600	78	5.47
7	5045	57	0.27	600	72	6.47
10	3700	100	0.32	600	77	7.56
15	2470	175	0.37	600	80	7.92
20	1850	255	0.49	750	81	12.44
25	1480	320	0.61	1050	79	19.38
30	1235	455	0.63	1050	79	23.07
40	925	580	0.66	1200	77	25.96
60	630	1000	0.7	750	87	33.97
Product name	mesh wire cloth filter disc
Material	ss304 316 316L
Core Components	Engine,Pressure vessel,Pump
Thickness	0.2mm / 0.05mm~3.5mm / 0.5mm-1mm / According to customer requirements

3. Product characteristics

Stainless steel sintered fiber web is a kind of multi pore deep filter media, sintered with stainless steel fiber at the high temperature.The filter elements enjoy the advantage of high porosity, large filter area and good dirt holding capacity, and can also be used repeatly after chemical cleaning.

6. Product use

1.Water treatment equipment filter

2.Petroleum chemical industry

3.Oil field pipeline filter and fuel refueling equipment filter

4.Pharmaceutical and food processing filed

5.Filter tube can use with the deep well pump, dive the water pump, also may use in the water-treating equipment,

the environmental protection, the sea water transforms into the industrial water and

life use water desalination treatment, running

6.water treatment, water softening treatment, the petroleum industry.
